Parameters⁴

• Resonance Frequency126 Hz
• Re5.2 Ω
• Qes0.39
• Qms4.6
• Qts0.36
• Vas6.0 dm³ (0.21 ft³)
• Sd132.0 cm² (20.46 in²)
• η₀3.0 %
• Xmax2.5 mm
• Xvar1.5 mm
• Mms6.0 g
• Bl8.2 Txm
• Le0.6 mH
• EBP323 Hz

Mounting and Shipping Info

• Overall Diameter187 mm (7.36 in)
• Bolt Circle Diameter172 mm (6.77 in)
• Baffle Cutout Diameter145.0 mm (5.71 in)
• Depth78 mm (3.07 in)
• Flange and Gasket Thickness11 mm (0.43 in)
• Air Volume Occupied by Driver0.8 dm³ (0.03 ft³)
• Net Weight2.4 kg (5.29 lb)
• Shipping Units1
• Shipping Weight2.6 kg (5.73 lb)
• Shipping Box210x210x125 mm (8.27×8.27×4.92 in)

1 2 hours test made with continuous pink noise signal within the range Fs-10Fs. Power calculated on rated nominal impedance. Loudspeaker in free air.

2 Power on Continuous Program is defined as 3 dB greater than the Nominal rating.

3 Applied RMS Voltage is set to 2.83 V for 8 ohms Nominal Impedance.

4 Thiele-Small parameters are measured after a high level 20 Hz sine wave preconditioning test.
